AGSS (Venturi type)
Product Details:
X
Product Description
For the transfer of excess residual gases during inhalation anesthesia to a suitable disposal point. All-metal design, display sign for operational control, with ejector for vacuum generation. One-handed operation during coupling and uncoupling, unlocking via plug sleeve. Completely mounted in stainless steel housing, with stainless steel front panel (for flush or hollow wall mounting). Design of the terminal unit complies with DIN EN ISO 9170-2.
| Material | Brass, housing and front plate stainless steel |
| Capacity | Min. 50 l/min (500 kPa) |
| Inlet | Copper tube 8x1 mm flexible hose PA 6 mm |
| Outlet | Copper tube 15x1 mm corrugated tube 15 mm |
| Marking | Color coding according to DIN EN ISO 9170-2 (standard magenta) |
- Brass Fixture
- Gas Inlet
- Spring
- Check Valve
- Check Valve Housing
- Spring
- Coin
- Rubber Disk
- Internal Gas Coding Body
- Body Spring
- Lock Nut
- Lock Nut Housing
- Release Cup
- Maintenance Valve
- Gas Outlet Suction Adaptor
